Reversible Plate Compactor RP 2414 Petrol

Forward and reverse compaction. Working width 50-75 cm. Self tightening clutch-for long v-belt life. Reinforced and strengthened base plate, especially designed for tough jobs. Easy to mount transport wheels. Ideal compactor for confined areas. Especially suitable for compaction in utility trenches, along highways, parking areas along foundations, walls and abutments. Handle locks in one swift motion, allowing easy transport in the upright position. Extra strong anti-vibration mounting brackets.

SPECIFICATIONS

Reversible Plate Compactor Frame

Reversible Plate Compactor Frame

Model Name RP 2414 Petrol

Plate Size W x L (mm) 500 x 642

Centrifugal Force (kg) 2400

Compaction Area (m²/hr.) 600

Dry Weight (kg) 149

Country of Origin India

Engine

Engine

Engine Model Name GX160

Engine Type 4-stroke, OHV, single cylinder, Air cooled engine inclined by 25°

Net Power kW (hp) @ rpm 3.6 ( 4.8 ) @ 3600

Cont. rated power kW (hp) @ rpm 2.5 ( 3.4 ) @ 3000, 2.9 ( 3.9 ) @ 3600

Compression ratio 9.0 : 1

Bore X Stroke (mm) 68 x 45

Fuel Type Unleaded Petrol

Fuel Tank Capacity (L) 3.1

Fuel cons. at cont. rated power (L/h @ rpm) 1.4 @ 3600

Ignition System Transistor Type Magneto Ignition

Engine Oil Capacity (L) 0.6

Recommended Oil Grade SAE 10W-30 API SE or higher

Cylinder sleeve type Cast Iron Sleeve

Engine Dry Weight (kg) 15.1

Dimensions L x W x H (mm) 312 x 362 x 346
