Power Reaper RPR160-1200

Wide Harvest Coverage - With a power packed performance it can reap large areas in very less time. Quick & Efficient Crop Harvesting - Efficient cutting mechanism to harvest crops like Wheat, Rice, Johar, Maize etc. Save Labor Cost - Saves the labor cost of multiple people. Low Cost of Operation - It is easy to use and maintain, has good fuel efficiency and requires low cost to operate.

SPECIFICATIONS

Power Reaper Frame

Power Reaper Frame

Model Name RPR160-1200

Maximum Power kw (hp) @ rpm 4.8 @ 3600

Transmission 1 Forward / 1 Reverse

Cutting Height (cm) 2.54 to 5.08

Cutting Width (mm) 1200

Conveyor Mechanism Chain drive & Star Wheel (4 Rows)

Field Coverage (Acre/hrs.) 1.3 / 1.7

Operating Speed (km/hrs.) 2.9

Dry weight (kg) 120 (approx.)

Engine

Engine

Engine Model Name GX160

Engine Type 4-stroke, OHV, single cylinder, Air cooled engine inclined by 25°

Net Power kW (hp) @ rpm 3.2 (4.3) @ 3600

Cont. rated power kW (hp) @ rpm 2.5 (3.4) @ 3000, 2.9 (3.9) @ 3600

Compression ratio 9.0 : 1

Bore X Stroke (mm) 68 x 45

Fuel Type Unleaded Petrol

Fuel Tank Capacity (L) 3.1

Fuel cons. at cont. rated power (L/h @ rpm) 1.4 @ 3600

Ignition System Transistor Type Magneto Ignition

Engine Oil Capacity (L) 0.60

Recommended Oil Grade SAE 10W-30 API SE or higher

Engine Weight Dry (kg) 15.1

Dimensions L x W x H (mm) 312 x 362 x 346
