Description
The Honda GX430 is a compact, air-cooled 4-stroke OHV engine with a 425 cm³ displacement, delivering up to 9.6 kW at 3,600 rpm. It combines advanced fuel-efficient combustion, a compression-release mechanism for effortless starting, and shaft-balancing technology to minimize vibration and noise. An precision governor ensures stable RPM under load, making the GX430 ideal for a wide range of industrial and commercial applications.
DESCRIPTION
The Honda GX430 is a rugged, air-cooled 4-stroke OHV engine with a 425 cm³ displacement (88 × 70 mm) that packs 9.6 kW and 28.5 Nm of torque at 3,600 rpm into a 32 kg package (387 × 469 × 453 mm). It burns just 4.5 L/h of E10 fuel under load, thanks to advanced combustion technology, and its 6.1 L tank and 1.1 L oil capacity ensure long run times between service. A compression-release mechanism delivers effortless recoil starts, while Honda’s shaft-balancing system and dual/low-profile air cleaner minimize vibration, noise, and dust ingestion for durable, quiet operation. The CDI-type magneto ignition and recoil/electric starter options guarantee reliable firing, and an advanced governor holds engine speed steady under fluctuating loads—making the GX430 an ideal power source for generators, pumps, compressors, construction gear and agricultural machinery.
SPECIFICATIONS
Engine
Engine
Compression ratio 9.0
Bore X Stroke (mm) 88.0x70.0
Fuel Type E10
Fuel Tank Capacity (L) 6.1
Ignition System CDI type magneto
Engine Oil Capacity (L) 1.1
Starting System Recoil/Starter motor
Dimensions L x W x H (mm) 387x469x453
Why Choose the Honda GX430?
The Honda GX430 is engineered for users who demand a powerful and reliable engine for various applications. Its advanced OHV design, high power output, and durability make it an excellent choice for agricultural machinery, recreational equipment, and industrial tools. Whether you need a dependable engine for nut cutters, go-karts, or concrete cutters, the GX430 provides superior performance and efficiency, ensuring optimal results and long-term satisfaction.
Engine Warranty Terms & Conditions
1. Warranty Period
Two year from the date of purchase for Non-Commercial use by customer.
Two year from the date of purchase for Commercial/ Rental use by customer.
2. Warranty Obligation
Repair or replacement of defective part(s ), at any authorised dealer, free of charge, if found defective by reasons of defective material or poor workmanship.
3. Warranty Service
To obtain warranty service the complete set must be presented to any of authorised dealer/service point at customer's risk and expense.
4. Terms and Condition
To qualify for warranty, Honda Engine must be set up by OEM and periodically serviced as per the maintenance schedule, provided in the Owner's manual by an authorised Honda dealer or Service point and the details updated in the maintenance records. Ensure to get it recorded after every service availed by the Dealer / Service point representative.
Presentation of this warranty & free service coupon booklet.
Warranty does not include:
Normal / natural wear & tear and normal deterioration of paint or other appearances.
Failures resulting from unauthorised modifications or repairs.
Failures resulting due to not availing of free service within the stipulated time
Rubber parts, Hardware items like Nuts & Bolts, Element Air Cleaner, Filters, Electrical Wires, Spark Plug, Gaskets, Starter Rope, Oil and Petrol.
Damages or failures resulting from misuse, operational faults, negligence, abnormal use, insufficient care, over-loading, accident or fire from external source, theft, chemical fall out, stone chipping, industrial pollution, or transportation.
Failures due to usage of non-recommended or adulterated engine oil and fuel. Failures due to usage of mixture of engine oil and fuel.
Normal phenomena such as noise and vibrations.
Incidental or consequential damage like inconvenience or commercial loss.
Any part or labour incurred in normal maintenance services.
Failures resulting from usage of non-genuine spare part (s).
